Default email texts sent by Vantage include ABBYY-specific information, such as ABBYY customer support emails, GDPR notices from ABBYY, and footers with ABBYY copyrights. You can modify the templates for these emails to include your own details and make them specific to your company.

​
Available Email Templates

Vantage offers the following email templates:
Email TemplateIDCultureSubject Template ParametersBody Template Parameters
Invitation email sent to the tenant administrator of a newly created tenantE6F03F64-B982-49C6-B336-251CA6C45FFEenproductNameuserName - the name of the user to whom the email is being sent, productName - the name of the product, invitationUri - the invitation link to create an account
Invitation email sent to the newly created tenant6C5DBE28-0A2C-4EB7-82DC-04173DC75418enproductNameuserName - the name of the user to whom the email is being sent, productName - the name of the product, invitationUri - the invitation link to create an account
Email with a password reset link requested by a user on the Vantage login page701B077A-20EA-42B8-A71E-AB3EA5996039enN/AdisplayName - optional display username provided during registration, callbackUrl - the link to reset password, expireHours - the number of hours until the link expires
Email about a successful skill export to a shared folderB5A03F64-B982-49C6-B336-251CA6C45FFEenN/AuserName - the user email address, skillName - the skill that is being exported, folderPath - the path to the shared folder
Email about an unsuccessful skill export to a shared folderF3C4BD68-B9FF-439F-A719-5B4F62263C4EenN/AuserName - the user email, skillName - the skill that is being exported, errorMessage - the error message body

​
Modifying an Email Template

To modify an email template, follow these steps:
  1. Get access to the Vantage mail service
  2. Get the email template details
  3. Update the email template

​
Getting Access to the Vantage Mail Service

To get access to the mail service:
  1. Get access to the Mail service API through http://localhost:8080 or another port:
kubectl -n abbyy-vantage port-forward $(kubectl get service -n abbyy-vantage --selector='app.kubernetes.io/name=mail' -o name) 8080:80
Sample terminal output:
Forwarding from 127.0.0.1:8080 -> 8080
Forwarding from [::1]:8080 -> 8080

​
Getting the Email Template Details

To get the markup for an existing email template, send a GET request to the templates resource (http://localhost:8080) as follows:
GET http://localhost:8080/api/v1/templates/{templateId}
Sample response:
{
  "localizedTemplates": {
    "en": {
      "subjectTemplate": "Your invitation to {{productName}}",
      "bodyTemplate": "<body>...</body>"
    }
  },
  "id": "<templateId>",
  "createTime": "2022-04-06T07:23:52.903261+00:00",
  "updateTime": "2022-04-06T07:23:53.137142+00:00"
}
The response will not contain the attachments, which will instead be placed in the email template. They must be specified and can additionally be modified when updating the template.

​
Updating an Email Template

To replace an email template, send a PUT request to the templates resource:
PUT http://localhost:8080/api/v1/templates/{templateId}
Request body:
{
  "culture": "en",
  "subjectTemplate": "subject template",
  "bodyTemplate": "body template",
  "attachments": [
    {
      "contentType": "attachment MIME",
      "contentId": "guid",
      "fileName": "image name used in body as cid",
      "content": "file content in base64 string"
    }
  ]
}

​
Template Elements

FieldTypeDescription
templateIdGUIDIdentifier of the email template to be modified
culturestringTemplate language. Currently, only English (en) is supported
subjectTemplatestringEmail header text template. See the previous section for information on how to get the current value
bodyTemplatestringEmail body template. See the previous section for information on how to get the current value
attachments[].contentTypestringMIME type of the attachment (for example, image/png)
attachments[].contentIdstringUnique identifier for the attachment
attachments[].fileNamestringAttachment file name, can be used in the body as CID
attachments[].contentbase64stringAttachment file encoded in base64 format
The subject and body template parameters must remain unchanged. Do not add, remove, or modify them.
Always include all attachments, even if you don’t intend to modify them. The request completely replaces the email template.

​
Default Attachments

Every Vantage email template contains these four attached images:
CIDMIME TypeImage
logo-vantage-logo-normal.pngimage/pngABBYY Vantage logo
600-px-copy-6.pngimage/pngDecorative header image
[email protected]image/png
[email protected]image/png

​
Sample Request

PUT http://localhost:8080/api/v1/templates/E6F03F64-B982-49C6-B336-251CA6C45FFE

{
  "culture": "en",
  "subjectTemplate": "Your {{productName}} account information",
  "bodyTemplate": "<body><table ...>...<img ... src=\"cid:logo-vantage-logo-normal.png\" alt=\"ABBYY Vantage\" />...Dear {{userName}},...</body>",
  "attachments": [
    {
      "contentType": "image/png",
      "contentId": "4dcc3114-b7ff-48b5-902a-8fbd673d6acd",
      "fileName": "logo-vantage-logo-normal.png",
      "content": "iVBORw0KGgoAAAANSUhEUgAAALoAAAAcCAMAAADhlVUwAAAA..."
    },
    {
      "contentType": "image/png",
      "contentId": "e243efa2-55ed-4f07-a1e0-27d55460decc",
      "fileName": "600-px-copy-6.png",
      "content": "iVBORw0KGgoAAAANSUhEUgAAAlgAAACkCAMAAAB8d6ClAAAA..."
    },
    {
      "contentType": "image/png",
      "contentId": "d57f26bb-43b6-41a3-b356-3f53dfbd28d7",
      "fileName": "[email protected]",
      "content": "iVBORw0KGgoAAAANSUhEUgAAACAAAAAgCAMAAABEpIrGAAAA..."
    },
    {
      "contentType": "image/png",
      "contentId": "df64ab94-9c7f-49d1-93bf-f7ba48eb2a98",
      "fileName": "[email protected]",
      "content": "iVBORw0KGgoAAAANSUhEUgAAACAAAAAgCAMAAABEpIrGAAAA..."
    }
  ]
}

​
Converting Files to Base64

To get the base64 string representation of a file, execute the following command:
[Convert]::ToBase64String([IO.File]::ReadAllBytes("full path to file"))
