Properties
Name | Type | Description |
|---|---|---|
Specifies the active tool for blocks and image editing. | ||
Specifies whether Image Viewer should scroll through all pages of the document. If this property is FALSE, Image Viewer scrolls through the selected page only. By default, the value is TRUE. | ||
Specifies whether the bottom pane of Image Viewer is enabled. If this property is FALSE, bottom pane is not displayed. By default, the value is TRUE. | ||
Specifies whether the caption pane of Image Viewer is enabled. If this property is FALSE, caption pane is not displayed. By default, the value is TRUE. | ||
Specifies whether the context menu of Image Viewer is enabled. If this property is FALSE, context menu is never displayed. By default, the value is TRUE. | ||
Provides access to the commands available in Image Viewer. See the list of commands available in Image Viewer. | ||
Specifies the document page connected to Image Viewer. | ||
Specifies whether recognized fragments should be highlighted on the image during recognition. This property allows you to watch the progress of recognition. By default, the value is TRUE. | ||
Specifies whether Image Viewer is locked. This property is useful in the following situations:
In this case, we recommend that you set this property to TRUE before analysis, recognition, synthesis or export, and set it to FALSE after the end of the operation. In this case, the document cannot be spoilt from Image Viewer. By default, the value is FALSE. | ||
Provides access to the settings of the context menu. | ||
Specifies the default processing parameters for a document. These parameters are used if analysis, recognition, and synthesis processes are called directly from Image Viewer. If Image Viewer is connected to Component Synchronizer, use the IComponentSynchronizer::ProcessingParams property to change parameters used for processing. If you change processing parameters via the property of Image Viewer, errors may occur. | ||
Provides access to the collection of indices of the pages selected in the Image Editor dialog box. | ||
Specifies the path to the folder which contains files with the settings of Image Viewer. Other Visual Components have the same property. Each Visual Component should use its own folder with settings. The value of this property is constructed from the path to the folder, in which ABBYY FineReader Engine stores user-specific data, and the name of its subfolder. By default, the folder with user-specific data is the FineReader Engine data folder. It can be changed during initialization of FineReader Engine. The default name of the subfolder is an arbitrary GUID. To change the name of the subfolder, you should specify the new name in the properties of the component in Visual Studio at design time. If you try to specify the value of the property at run time, this value is ignored. If you add the component to a form in Visual Studio when designing, the value of the property is defined either automatically with the default value, or manually with a custom value. In both cases the value is defined at design time. If for some reason the value of the property is not defined at design time (e.g., if you generate the component dynamically at run time), the component creates a new folder with the settings each time the component is initialized. To avoid multiplication of the folders, you should delete the created settings folder after the component deinitialization. In this case, you can use only the default settings of the component and cannot save the settings between sessions. | ||
Specifies the title of the Image Viewer component. By default, it is “Image”. | ||
Provides access to the toolbar settings. | ||
Specifies the scale of the image in percentage points. This property can be also set to one of the ScaleTypes constants. By default, the value is ST_BestFit, which means that the best fit is automatically selected. | ||
Stores the coordinates of the visible document area in pixels. The coordinates are relative to the document image. | ||
__int64, read-only | Returns the window handle of the client area. | |
Stores the coordinates of the zoom area rectangle in pixels. The coordinates are relative to the document image. | ||
Specifies whether the zoom area should be marked on the image with dotted rectangle. By default, the value is TRUE. |
Methods
| Name | Description |
|---|---|
| CenterOnDocumentPoint | Scrolls image view so that the specified point is positioned at the center of the view. |
| DocumentToScreen | Converts coordinates of the specified point on the document image into screen coordinates. |
| GetSelectedBlocksIndices | Returns the collection of indices of selected blocks. |
| GetSelectedCells | Returns the surrounding rectangle of selected cells in the specified table block. |
| Prints the image. | |
| ScreenToDocument | Converts screen coordinates of the specified point into coordinates on the document image. |
| SetSelectedBlocksIndices | Sets blocks selection. |
| SetSelectedCells | Sets selected cells of the specified table block. |
| ShowDocumentArea | Scrolls image view so that the document area with the specified coordinates becomes visible (as far as possible). |
| UpdateOptions | Updates the settings specified in the Options dialog box of Image Viewer. You may need to call this method, if the options have been changed in some other Visual Component, to update the options of Image Viewer to the current state. |
