Add the connector assemblies to your ABBYY FlexiCapture project before you set up document export.

​
Add the assemblies

1

Open the project

Open the ABBYY FlexiCapture Project Setup Station, and then open the project.
2

Open the Document Definition

  1. Click Project → Document Definitions to open the list of Document Definitions available for the project.
  2. Select the Document Definition you want to specify new export settings for.
  3. Click Edit.
3

Open the .Net References tab

Click Document Definition → Document Definition Properties, and then click the .Net References tab.
4

Add each library

  1. Click Add.
  2. In the Add Assembly dialog box, select Attached file from the Type drop-down list.
  3. Browse for the AfcDmsConnector.dll, DmsConnector.dll, UiPathConnector.dll, and Newtonsoft.Json.dll files.
Screenshot of the Add Assembly dialog box in the ABBYY FlexiCapture Project Setup Station, with Attached file selected in the Type drop-down list and the connector DLL files listed on the .Net References tab of the Document Definition properties.
5

Save the Document Definition

Save the Document Definition to apply the changes.
The next step is to create an export profile. For more information, see FlexiCapture export profiles for UiPath.
